The History of Auger Fabrication Filling Accessories
For more information regarding this post or for interest in purchasing filling accessories, please contact your local Auger Fabrication salesperson.
From the very beginning in 1969, All-Fill Inc. and Auger Fabrication offered two different set ups that became commonly referred to as small & large tooling. Both style involved many parts and came with limitations. As time passed, the name associated with the small tooling became “old style small” and the large tooling “old style large.”
“Old Style-Small”
2.5” opening hopper
7 ¼” & 13 ¼” long auger shaft
Augers: ½” stem with 3 1/16” cross pin
Standard Auger Lengths: 10” & 18”
Standard Funnel Lengths: 4 9/16” & 12 9/16”
Funnel Hub Diameter: 3.5”
Only for #4 through #32 auger & funnel
“Old Style-Large”
3.25” opening hopper
6 5/8” & 10 5/8” long auger shaft
Augers: 5/8” stem with 1/4” cross pin
Standard Auger Lengths: 13” & 18”
Standard Funnel Lengths: 5 9/16” & 12 9/16”
Funnel Hub Diameter: 4”
Only for #4 through #32 augers & funnels
In 1997 Auger Fabrication introduced “Universal Style tooling” which eliminated & consolidated the aforementioned filling accessories. This design change allowed every filling machine to accept every size of standard filling accessory. Now, all filling accessories consist of the following:
“Universal Style Tooling”
3.25” opening hopper
6 5/8” & 10 5/8” long auger shaft
Augers: 5/8” stem with 1/4” cross pin
Standard Auger Lengths: 13 1/8” & 20 1/8”
Standard Funnel Lengths: 5 9/16” & 12 9/16”
Funnel Hub Diameter: 4”
For more information regarding this post or for interest in purchasing filling accessories, please contact your local Auger Fabrication salesperson. As always, product tests are free of charge in our fully stocked test lab located in Exton, PA. We look forward to seeing you soon and thank you for your continued interest in our fine family of companies.
